Flashing bar directly beneath the 0, what does it mean?

Discussion in 'Canon Film SLRs' started by Web-Betty, May 11, 2017.

  1. Web-Betty

    Web-Betty New Member

    Joined:
    May 11, 2017
    Messages:
    7
    Equipment:
    Canon EOS-3, 28–80/3.5–5.6, 50/1.8 I
    I just purchased an EOS-3 and am learning all its parts. In the LCD panel, the very middle bar of the film and battery indicator (directly below the "0" of the exposure compensation scale) is blinking. I have no idea what this means and can't seem to find it in the manual.

    Can someone help? Thanks! :)


  2. pjv

    pjv Guest

    I hope this screenshot of the LCD panel helps. :)


  3. Web-Betty

    Web-Betty New Member

    Joined:
    May 11, 2017
    Messages:
    7
    Equipment:
    Canon EOS-3, 28–80/3.5–5.6, 50/1.8 I
    Thanks for the quick reply! I have the manual and this was the first page I reference. But the bar in question is not highlighted as anything special. The red arrow in the screenshot is pointing to the bar that is flashing.


  4. pjv

    pjv Guest

    Does it flash when you have a film in or when empty?

  5. Bob L

    Bob L New Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    20
    Location:
    La Vienne, France
    If I remember correctly, the battery condition indicator works like this;
    3 bars on solid.....fully charged
    2 bars on solid.....1/2 charge
    1 bar on solid.......1/4 charge
    1 bar flashing.......almost expired.
    bc (elsewhere on the display......change battery.

    Hope that helps
    Bob

    Vasile Guta-Ciucur likes this.
  6. johnsey

    johnsey Site Moderator Staff Member Site Supporter

    Joined:
    Apr 21, 2017
    Messages:
    2,131
    Location:
    Fargo, ND
    Equipment:
    5dMk4, 5dsR, 5dMk2, 20D, 70-200 2.8L IS, 100mm 2.8 Macro USM, 50mm 1.4, 85mm 1.8, 17-40mm 4.0L, TS-E 24mm 3.5L II, Rokinon 14mm 2.8; Pixma Pro-100
    I don't have experience with the specific camera but it seems to me that it is indicating that the exposure is not over or under exposed. Flashing instead of steady burn probably means that it's not quite register right at zero.

  7. Web-Betty

    Web-Betty New Member

    Joined:
    May 11, 2017
    Messages:
    7
    Equipment:
    Canon EOS-3, 28–80/3.5–5.6, 50/1.8 I
    I didn't notice it when I was loading film. But it's doing it now with film loaded.

  8. Bob L

    Bob L New Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    20
    Location:
    La Vienne, France
    I think that's because there's a small microswitch in the film compartment.

    Bob

  9. Vasile Guta-Ciucur

    Vasile Guta-Ciucur Active Member Site Supporter

    Joined:
    Apr 29, 2017
    Messages:
    128
    Location:
    Pistestii din Deal, Gorj, RO
    Equipment:
    Canon EOS 100D
    Canon Lens EF-S 18-55mm 1:3.5-5.6 III
    It would help an actual capture of the screen, with the other informations displayed... You can't diagnose without that.

  10. Bob L

    Bob L New Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    20
    Location:
    La Vienne, France
  11. Web-Betty

    Web-Betty New Member

    Joined:
    May 11, 2017
    Messages:
    7
    Equipment:
    Canon EOS-3, 28–80/3.5–5.6, 50/1.8 I
    I'm pretty sure it has nothing to do with the battery check function. As I've stated, I've gone through the manual. :)

    Here's a link to a quick, 4-second video illustrating the blinking in question.

    Vasile Guta-Ciucur likes this.
  12. Bob L

    Bob L New Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    20
    Location:
    La Vienne, France
    It makes more sense after seeing the video. You're in auto exposure mode "P" on the screen and the flashing icon is showing you that you've not got any EC dialed in....see page 29 of your manual.

    Bob

    Vasile Guta-Ciucur likes this.
  13. Web-Betty

    Web-Betty New Member

    Joined:
    May 11, 2017
    Messages:
    7
    Equipment:
    Canon EOS-3, 28–80/3.5–5.6, 50/1.8 I
    Mystery solved, but found on page 75! :D

    Thanks @Bob L for pointing me in the right direction. The bar that flashes is used to indicate what your exposure is set to. When you dial in exposure compensation, the flashing bar moves to the corresponding +/-.

    Thanks to all who responded!

    Bob L, pjv and Vasile Guta-Ciucur like this.
