Sign the Sesnor is going?

Discussion in 'Technical Troubleshooting' started by Az Skies Photography, Apr 28, 2017.

  1. Az Skies Photography

    Az Skies Photography New Member Site Supporter

    Joined:
    Apr 28, 2017
    Messages:
    1
    Equipment:
    Canon T21, 18-55mm EFS, 55-250mm EFS, 70-200mm f/2.8 IS II USM
    Monday I had these weird black areas show up in photos. It cleared after a few minutes. But now I am seeing areas that are bright and dark in the same locations. Is this a sign my sensor is failing?


    Attached Files:


  2. Phil

    Phil Administrator Staff Member Site Supporter

    Joined:
    Feb 20, 2017
    Messages:
    251
    Location:
    Rochester, NY
    Equipment:
    Canon 7D - 50mm F1.8, 70-200mm F4, 17-70mm F2.8-4.5
    Do you have another lens to check? My feeling is there's some blockage in the lens and not the sensor. If the sensor was failing the edges wouldn't be as soft.

  3. marki3rd

    marki3rd New Member Site Supporter

    Joined:
    Apr 28, 2017
    Messages:
    1
    Equipment:
    Canon T5i, SX60 HS, EF 55mm 1:18 STM, EF-S 18-55mm 1:3.5-5.6 IS STM, EF-s 18-135mm 1:3.5-5.6 IS STM EF-S 55-250mm 1:4.5-5.6 IS STM, Sigma 70-300mm 1:4.0-5.6 APO DG MACRO, Sigma 28-80mm 1:3.5-5.6 II MACRO
    I suspect it is not a Sensor issue, but possibly an issue with the SD Card or the hardware/firmware that writes to the SD Card. I would start by trying a different SD Card that has been formated in that camera.

  4. Ray-UK

    Ray-UK Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    151
    Location:
    Rochester, UK
    Equipment:
    Canon 7D Mk II, Canon 10-22, Canon 24-105 L Mk 1, Canon 24mm 2.8, Canon 55-250 STM, Canon 100mm usm macro, 3x Metz 58 AF1 & too many film cameras, mainly Pentax
    More likely the shutter :(

    Kharan likes this.
  5. drougge

    drougge New Member Site Supporter

    Joined:
    Apr 28, 2017
    Messages:
    2
    Location:
    Malmö
    Equipment:
    5D2, "Zeiss" (Cosina) 35/2 and 50/1.4, EF85/1.8, lots of lenses in other mounts
    Definitely the shutter. At least for the straight black area, the angled problems are stranger, like the shutter only stops on one side. I would expect it to get stuck pretty permanently if it went sideways like that, but apparently not.

    Mirror problems also look a bit like this, but they pretty much have to be towards the bottom of the picture (top of the sensor) because that's where the mirror is attached.

    Kharan likes this.
  6. Craig Sherriff

    Craig Sherriff Well-Known Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    3,177
    Location:
    Tasmania, Australia
    Equipment:
    60D, 10D, 50D 1dmark3, T70, AV1, lenses ranging from 28mm to 600 mm, canonet Junior, Canonet QL 25, Mamiya C3 and 3 lens sets,Mamiya 645 pro TL and 3 lenses. Pentax MG and various lenses, Toyoview 4 * 5 inch large format camera,Calimat C1 8*10 inch ultra large format camera.
    With various things that could cause the problem, instead of guessing, start to eliminate some of possibilities.1. thoroughly clean the lens 2. clean the sensor 3. replace the memory card. If there is still a problem Have it serviced

  7. Kharan

    Kharan New Member Site Supporter

    Joined:
    Apr 29, 2017
    Messages:
    2
    Az,
    Like it was mentioned before, it definitely seems to be a shutter problem. Try shooting in single mode at first, and see if the problem happens again. If it does, try burst shooting at max speed a couple of times (x5 1-2 second bursts). If it clears after doing that, then it's definitely the shutter assembly.
