Vintage Lenses on modern cameras

Discussion in 'General Talk' started by Caladina, Oct 24, 2020.

  1. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    the red line stops at the infinity mark, lines up with it


  2. GDN

    GDN Well-Known Member

    Joined:
    Jul 22, 2018
    Messages:
    1,721
    Location:
    South Island, NZ
    Equipment:
    A little Canon stuff
    And I am assuming the lens group moves in and out as you rotate the focusing ring.

    Gary

  3. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    yes the whole lens group moves, no loose sounds,
    does the picture of the rear element look correct, i wasn't sure if there may have been a missing one with the amount thread it has there

  4. GDN

    GDN Well-Known Member

    Joined:
    Jul 22, 2018
    Messages:
    1,721
    Location:
    South Island, NZ
    Equipment:
    A little Canon stuff
    My guess is that it has been disassembled and reassembled wrong. It really can't be that hard to remove the rear screws and change the helicoid so that it lines up properly. A little trail and error.

    But sadly, I am out of idea's for you Caladina. Craig is going to be more help to you from now on.

    Gary

  5. Craig Sherriff

    Craig Sherriff Well-Known Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    1,798
    Location:
    Tasmania, Australia
    Equipment:
    60D, 10D, 50D 1dmark3, T70, AV1, lenses ranging from 28mm to 600 mm, canonet Junior, Canonet QL 25, Mamiya C3 and 3 lens sets,Mamiya 645 pro TL and 3 lenses. Pentax MG and various lenses, Toyoview 4 * 5 inch large format camera,Calimat C1 8*10 inch ultra large format camera.
    Caladina, I have had a quick look but it may take some time as I think it is under my house in a heap of photo gear I have stored there, I put a image up as soon as I can find it.

  6. Craig Sherriff

    Craig Sherriff Well-Known Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    1,798
    Location:
    Tasmania, Australia
    Equipment:
    60D, 10D, 50D 1dmark3, T70, AV1, lenses ranging from 28mm to 600 mm, canonet Junior, Canonet QL 25, Mamiya C3 and 3 lens sets,Mamiya 645 pro TL and 3 lenses. Pentax MG and various lenses, Toyoview 4 * 5 inch large format camera,Calimat C1 8*10 inch ultra large format camera.
    Caladina, I still can not find my 50mm version of your lens, so I have looked at my other M42 mount lenses and they are all the same. When my lens are focused to infinity the rear element is extended to the rear, in your images it does not appear to be happening, as Gary suggested the helicoil may be miss-aligned but I am only guessing . I would be interested to see how you go with your secondM42 lens when it arrives. I don't know what the Op-shops are like where you live but this may be a good place to pick up a cheap M42 mount lens if the next lens takes too long to arrive.

    Last edited: Oct 31, 2020
  7. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    ok, i'll wait for the next one,
    when i used the extension tubes on their own to sit the lens at a closer distance than the lens elements would normally be on the M42 mount this would probably far exceed the closeness of the normal range when the lens helicoil is correctly mounted?
    i went from having the lens sitting on the camera flange to various distances using m mount extension tubes

  8. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    while i been waiting for the other M42 to turn up i have just seen a pic of the back of the lens on tinternet, looks like there is a lens/group missing from the rear.
    contacted the seller and have returned it for a replacement.
    the one from t'internet.

    i did take a pic of the out going lens before i knew it had bits missing


    Last edited: Nov 3, 2020
  9. Craig Sherriff

    Craig Sherriff Well-Known Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    1,798
    Location:
    Tasmania, Australia
    Equipment:
    60D, 10D, 50D 1dmark3, T70, AV1, lenses ranging from 28mm to 600 mm, canonet Junior, Canonet QL 25, Mamiya C3 and 3 lens sets,Mamiya 645 pro TL and 3 lenses. Pentax MG and various lenses, Toyoview 4 * 5 inch large format camera,Calimat C1 8*10 inch ultra large format camera.
    Caladina, it's a shame as these lenses do give good results, also it slows you down in focusing, which in turn forces you to think more about what you are taking. resulting in a better photos.

  10. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    yep, thats why i like the idea of using them, less clinical and more creative, as you can probably tell from i'm all about getting outside the box :)
    the guy has a retro camera shop so he thinks he may have a few others, i've not given up on using vintage lenses, just bad luck on a first attempt.
    you gotta have some ham fall out your sammich every once in a while.

  11. Marcus Rowland

    Marcus Rowland Member Site Supporter

    Joined:
    Apr 23, 2017
    Messages:
    312
    Location:
    London, United Kingdom
    Equipment:
    Eos 400D (Rebel XTi), Canon 18-55mm, lots of adapters for other lenses
    Nikon D7000, Nikon 18-55mm DX VR, Tamron XR 28-300mm, Nikon AF 50mm 1.4, Samyang 8mm f3.8, Vivitar S1 100-500 5.6-8, etc.
    Panasonic Lumix G1, 14-42 3.5-5.6, lots of adapters
    Pentax K200, Pentax 18-55mm
    Sony A230, Sony 18-70 3.5-5.6
    Sony NEX 5 body.
    Fuji FinePix S5700.
    Sony DSC-V1 with infrared kit.
    FLIR One thermal imaging camera.
    Fortunately we're very lucky with the Eos mount - there are very few lenses that can't be adapted to it easily. M42 is dead easy and I've had some very nice results with old Pentacon, Helios and Pentax lenses.
    Gallery of pictures with my 400D and a Helios 50mm f2 here
    https://www.flickr.com/photos/150868539@N02/albums/72157676487175697

    Since I'm in the used lens business I currently own a shed-load of adapters for my Eos, it's my main test-bed for lenses. Let's see if I can remember them all:

    Canon FD - has a corrective lens in the adapter but works well.
    C-mount (macro only)
    Exakta Varex
    Fujifilm FX - corrective lens type, not very good
    M39 for older Zenit lenses etc.
    M42 - two of these, one with a rim to press the stopdown pin, the other without.
    Minolta MD - Corrective lens type - I don't have one for Minolta AF any more since I have an old Sony Alpha
    Nikon - not used much since my main camera is a Nikon, but occasionally useful for lenses that have electronics faults etc. and won't play nice with the Nikon body. Or if I want to put one of my lenses onto the Canon for other reasons, of course.
    Olympus OM
    PK - not used much any more since I have a Pentax DSLR so I can test autofocus etc.
    Praktica bayonet
    QBM (old Rolleiflex etc.)
    Tamron Adaptall - not very good, it's just a solid adapter ring with nothing to control lens aperture and no chip, I usually use another mount and an adapter that has a chip.
    Yashica/Contax

    OK, I missed the C-mount lens since it's pretty useless but remembered the rest.

  12. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    great post thanks, is there a direct ef-m to pentax pk ?

    the only mount adapters i have at the moment are L39 and M42 to ef-m and M42 to ef

  13. Marcus Rowland

    Marcus Rowland Member Site Supporter

    Joined:
    Apr 23, 2017
    Messages:
    312
    Location:
    London, United Kingdom
    Equipment:
    Eos 400D (Rebel XTi), Canon 18-55mm, lots of adapters for other lenses
    Nikon D7000, Nikon 18-55mm DX VR, Tamron XR 28-300mm, Nikon AF 50mm 1.4, Samyang 8mm f3.8, Vivitar S1 100-500 5.6-8, etc.
    Panasonic Lumix G1, 14-42 3.5-5.6, lots of adapters
    Pentax K200, Pentax 18-55mm
    Sony A230, Sony 18-70 3.5-5.6
    Sony NEX 5 body.
    Fuji FinePix S5700.
    Sony DSC-V1 with infrared kit.
    FLIR One thermal imaging camera.
    I've seen them on sale, I don't have an EF-M camera (my mirrorless cameras are micro 4/3 and Nex) but you can get the adapters for about £8.50 upwards (if you don't mind buying from China) - I don't know which country you're in but eBay has dozens of them - the ones you want are tubes that look like they're about 30mm long, something like this. They're basically just dumb extension tubes.

    https://www.ebay.co.uk/itm/FOTGA-PK...-PK-Lens-to-for-Canon-EOS-M-EF-M/184408894119

    I have similar adapters for both of my mirrorless bodies. You can get VERY silly with mirrorless bodies, almost anything can be adapted to them.

    Last edited: Feb 20, 2021
  14. Caladina

    Caladina Well-Known Member

    Joined:
    Jan 30, 2020
    Messages:
    1,101
    Equipment:
    Canon M50
    Canon 18-45mm m, Canon 18-150mm m, Canon 55-200mm m, Canon 22mm m, Canon 28mm m macro,
    Sigma 100-400c ef, Sigma 18-35mm art ef,
    7artisans 7.5mm m, Laowa 100mm macro ef, laowa 9mm zeroD m, Vintage M42 Lenses:
    Ashi Super - Takumar 1.8 / 55mm,
    i'm in north london, :)
    looking for an M42 500mm takumar if you ever come across one

  15. Craig Sherriff

    Craig Sherriff Well-Known Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    1,798
    Location:
    Tasmania, Australia
    Equipment:
    60D, 10D, 50D 1dmark3, T70, AV1, lenses ranging from 28mm to 600 mm, canonet Junior, Canonet QL 25, Mamiya C3 and 3 lens sets,Mamiya 645 pro TL and 3 lenses. Pentax MG and various lenses, Toyoview 4 * 5 inch large format camera,Calimat C1 8*10 inch ultra large format camera.
    Not exactly a Takumar 500 mm but I have a Hanimar 400mm with a M42 mount and to go with it a 2x extender and a APS Autoplus 3x extender, the Hanimar 500mm looks like a piece of pipe with a focusing piece on the end and is very light. I must get them out and have a serious play with them one day. I have seen a few 400mm lenses with M42 and K mount but very few 500mm lenses down here in Tasmania, depending on what is available where you live, is a 400 mm and a 2x extender a option to look at ? The 400mm is a very nice lens to use. There is a second option worth a look and that is the 500 mm mirror lens, I have a Tamron 500 mm lens with a adaptall 2 mount version, draw- back is you can only have F8 for the aperture ( due to the mirror design ) but positives are Tamron have a variety of adapters to different cameras, for this lens, it is very short and I find a fair bit lighter then other 500mm and 600mm lenses, handy if you want hand held.
    The Tamron 500mm mirror lens has macro capability of 1:3 and using a 2x extender 1:1.5 from about 2 meters away , must try out my 3x extender and see if I can get 1:1.
    Draw-back is has some unusual out of focus area. If this lens tickles your interest have a look on youtube on the Tamron SP 500 mm mirror lens, there is some good in-depth video clips worth a look.

    Last edited: Feb 21, 2021
  16. Marcus Rowland

    Marcus Rowland Member Site Supporter

    Joined:
    Apr 23, 2017
    Messages:
    312
    Location:
    London, United Kingdom
    Equipment:
    Eos 400D (Rebel XTi), Canon 18-55mm, lots of adapters for other lenses
    Nikon D7000, Nikon 18-55mm DX VR, Tamron XR 28-300mm, Nikon AF 50mm 1.4, Samyang 8mm f3.8, Vivitar S1 100-500 5.6-8, etc.
    Panasonic Lumix G1, 14-42 3.5-5.6, lots of adapters
    Pentax K200, Pentax 18-55mm
    Sony A230, Sony 18-70 3.5-5.6
    Sony NEX 5 body.
    Fuji FinePix S5700.
    Sony DSC-V1 with infrared kit.
    FLIR One thermal imaging camera.
    It's been a VERY long time since I've had any long Takumars - I think the last were a 300mm in 2015-ish and a 200mm in 2018-ish ago. They just don't seem to come my way much. Loads of cheapo crap in that range, of course, but the big Takumars don't turn up at prices that make sense for a reseller. My current big lens is a Vivitar Series 1 100-500 for Nikon, which I got absurdly cheaply in a car boot sale, and it gives good enough results for my purposes but isn't up to really high quality work.

  17. John J Kowal

    John J Kowal New Member

    Joined:
    Feb 21, 2021
    Messages:
    5
    Equipment:
    5d, 550D, 350D, G12, Nikon D610, D300, D70, FE, FG, Sony IMX477R
    Tamron 135mm Adaptall 2 on a Caonon T2i. Technicolor cinestyle in-camera profile applied. DPP4 post processing.


    Attached Files:

  18. Craig Sherriff

    Craig Sherriff Well-Known Member Site Supporter

    Joined:
    Apr 25, 2017
    Messages:
    1,798
    Location:
    Tasmania, Australia
    Equipment:
    60D, 10D, 50D 1dmark3, T70, AV1, lenses ranging from 28mm to 600 mm, canonet Junior, Canonet QL 25, Mamiya C3 and 3 lens sets,Mamiya 645 pro TL and 3 lenses. Pentax MG and various lenses, Toyoview 4 * 5 inch large format camera,Calimat C1 8*10 inch ultra large format camera.
    John these are really nice lenses, I have two, a 28mm F2.5 to f32 and a 500mm mirror lenses
